SIGMATEK presents 7-inch Multitouch Panel

The latest addition to SIGMATEK's HMI portfolio, the ET 0710, combines compact plastic design with the latest processor architecture and a high-resolution 7-inch multitouch display. This slim operating panel is therefore ideal for smaller machines with limited space and price-sensitive applications that want to enhance with modern HTML5 visualization.

At its heart is a quad-core EDGE3 technology processor with four cores (4x 1.6 GHz), 2 GB LPDDR4 RAM, and 8 GB microSD memory. This allows even memory-intensive web HMI applications to be displayed smoothly.

Thanks to its projected capacitive glass surface, the fanless HMI can be operated precisely and intuitively using multi-finger gestures. The 7-inch widescreen with a resolution of 1.024 x 600 pixels displays colors and visualizations brilliantly. The LASAL VISUDesigner Tool (HTML5) offers a wide range of ready-to-use operating elements and controls for creating visualizations.

The ET 0710 has one Ethernet, one CAN, one USB 2.0 Type A, one USB 2.0 Type C, and one RS485 interface. The ET 0710-02 offers an additional Ethernet, CAN, and RS232 interface. The ET 0710-01 variant comes with 1x Gigabit Ethernet, 1x Ethernet, 2x CAN, 1x USB 2.0 Type A, 1x USB Type C, 1x RS232, 1x RS485, 1x LP-Bus, and 1x M-Bus. This allows users to select the panel or interfaces that best suit their requirements and achieve cost efficiency. The plastic housing of the ET 0710 also contributes to an optimized price-performance ratio and is designed for industrial use. A multi-status LED is located on the front.

The web HMI is developed for installation in control cabinets and has IP65 protection on the front.
